BSP female

Type: Screw to connect and disconnect coupling. High pressure by the screw connection and a good protection against accidental uncoupling. Very important is that the nut is fully tightened during connecting so that the valves are fully opened.
Material: standard white zinc plated carbon steel.

General information: This series is used in heavy hydraulic and industrial applications in presence of high pressure, vibrations and mechanical stress.
Connection: Metric bulkhead execution with BSP 3/4" - 1" female.
Seals: Nitrile rubber (NBR), back-up ring PTFE. On request with FKM (Viton) and EPM seals.
Fluid temperature: -20° C tot +110° C.
Note: Connecting under pressure is not possible.
